| Features | 1. The product is an epoxy thermistor with good stability and high reliability 2. Small size, sturdy structure, and easy installation |
| Scope of application | Temperature control of household appliances and medical equipment, temperature protection of charging battery packs and chargers |
| Operating temperature range | -30-90℃ |
| Thermal time constant | t≈13sec |
| Heat transfer coefficient | 3.5mw/℃ |
| Insulation resistance | DC50V Above 10MΩ |
| Resistance | R25=5K±1% (Can be customized according to customer requirements) |
| B value | R25/50=3380K±1% (Can be customized according to customer requirements) |
