| Features | 1.Sensors that can detect performance in low temperature environments 2.In the metal shell protective tube, the epoxy resin encapsulation structure |
| Scope of application | Refrigerator air conditioning temperature sensor |
| Operating temperature range | -30-125℃ |
| Thermal time constant | t≈15sec（Medium: liquid） |
| Withstand voltage | AC1500V 1sec |
| Insulation resistance | DC500V 100MΩ |
| Resistance | R25=10K±1% (Can be customized according to customer requirements) |
| B value | R25/85=3435K±1% ( Can be customized according to customer requirements) |
